CL-80/100/80C LLDPE Stretch Wrapping Film Plant
Main Technical Parameter of CL-80/100/80C LLDPE Stretch Wrapping Sheet Line
Width of Die Head of CL-80/100/80C LLDPE Stretch Wrapping Sheet Plant: 2350mm
Width of Film produced by CL-80/100/80C LLDPE Stretch Wrapping Sheet line: 2000mm
Max Extrusion Capacity of CL-80/100/80C LLDPE Stretch Wrapping Sheet Unit: 420kg/h
Max Rewind Diameter: 400mm
Screw Diameter: A:80mm
B:100mm
C:80mm
Thickness of Film produced by CL-80/100/80C LLDPE Stretch Wrapping Sheet Plant: 0.01-0.05mm
Structure of Film Layers: A/B/C or A/C/B/C/A
Liner Speed of Machine CL-80/100/80C LLDPE Stretch Wrapping Sheet Line: 200m/min
L/D Ratio of Screw: 30:1
Motor Power of Main Machine: 45/90/45kw
Total Power Consumption of machine CL-80/100/80C LLDPE Stretch Wrapping Sheet Unit: 100-250kw
Overall Dimensions(L*W*H): 12*5.6*4.5m
Total Weight: 17T
Features of Plastic Melt Metering Pump for CL-80/100/80C LLDPE Stretch WrappingSheet Making Unit
1.Cooling roller adopt big diameter design and special double deck runner,greatly improving the cooling effect in high speed producing process and ensure the same temperature of cooling roll surface.
2. The whole line adopts melt metering pump with precision sensor pressure system.Strictly control plastic extruder output, ensuring to make finished film stable and maintain a uniformity.
3. The whole line comes true fully automatic production, based on traditional automatic cut film,
increase high output, high linear speed and save labour cost.
Application of CL-80/100/80C LLDPE Stretch Wrapping Sheet Plant
The stretch film making by this machine is used for packaging goods like pictures.
Certificate of CL-80/100/80C LLDPE Stretch Wrapping Sheet Line
Packing of CL-80/100/80C LLDPE Stretch Wrapping Sheet Making Unit
After-Sales Service of CL-80/100/80C LLDPE Stretch Wrapping Sheet Plant
We offer warranty on product quality and lifelong maintenance services.
Our professional engineering team is constitutive of excellent technical staff.
We provide perfect after-sales service in time, give a good technical training to ensure stable running of machine.
We will respond to customer`s service requests and complaint in the shortest possible time and give a clear reply and solution to deal with in time.
At the same time,we sum up customer`s complaint and proposal in order to improve ourselves and better meet customers requirement. We will commit to improve our services quality, so that our customers will be most satisfied.
