Product Description:
Half Automatic Bottle Making Machine cost , PET Detergent Bottle Blow Molding Machine maufacturer

1. Max. Bottle volume: 10L
2. Machine capacity: 200-500BPH (2 cavities or 1 cavity)
3. Machine Power: 18 KW
4. Suitable bottle: water, cooking oiletc
5. Blower size: 1.80 X 0.75 X 1.78 M
6. Heater size: 2.25 X 0.51 X 1.40 M
7. Machine weight: 1500 KG (1 machine + 1 oven)

Manual Machine Pictures:
1. semi automatic pet bottle blow moulding machine adopt BOSCH(Germany brand ) & PARKER ( U.S.A Brand) pneumatic components. PLC use SIEMENS(Japan brand),Electric use SCHNEIDER (France brand),the configuration brand can be selected according to your requirement.
2. Infrared lamps,each power of group lamps can be adjusted to meet different preforms,
3. one worker is enough for operating the machine.
4. Stable performing with easy maintaining.
5. Touch screen, easy for operating the machine
6. High safety. high speed with high efficiency, economic.

Machine Parameters:
Model | Semi Automatic Blow Molding Machine Technical Parameter |
Output | Based on bottle shape | 200-500 pcs/h |
Product Specifications | Max.container diameter | 180mm |
Max.container height | 370mm |
Mold Specifications | Cavity | 1 cavity or 2 cavity |
Max. Mould thickness | 160-260mm |
Machine Power | Power Voltage | 380v 3Phase /220v 3Phase 50/60HZ |
Installed power/used power | 38kw/16kw |
Air Source | High pressure air compressor | 1.2m3/min 30Kg |
Air dryer | 1.5m3/min 30Kg |
Air filter | 1.5m3/min 30Kg |
Water chiller | Chilled water | 3HP (make your choice) |
Blowing machine size | Length*width*height/weight | 1800*750*1780mm/650kg |
Heater size | Length*width*height/weight | 2250*600*1400mm/350kg |
