RELIANCE MACHINERY DESIGN AND SUPPLY R-SLB Shrink Sleeve Applicator also called sleever, used on glass dropper bottle band caps.
sleeve binder, label inserting machine, shrink labeler and even called shrink labeling machine. The machine is used to apply or insert shrink sleeve label on the bottles/container. R-SLB manufactures all models for applying heat shrinkable sleeve label or neckbands which is commonly used on most food /E-Liquid Industries / pharmaceutical / chemical packages ranging from bottles, yogurt cups, margarine bowls and eye drop containers. Shrink sleeves can wrap and conform to a container's every curve, enabling complete decoration of unusual shapes from top to bottom with 360 degrees. Shrink sleeves are widely used to decorate everything from foods, beverages, cosmetic, medical and even personal products like eye drop, lipstick, lighter, marker pen.
The services available are:
> Fully automatic operation.
> No Bottle - No Sleeve-Feature(Eliminates Wastage).
> Can handle round glass / plastic bottles.
> Speed of 40 bottles to 80 bottles/min. depending on the cut length of the sleeve.
> Servo motors for more accuracy.
> Fitted with digital PLC control.
> Eye mark sensor for accurate cutting in printed sleeves.
> VFD used to increase or decrease the speed wherever necessary.
> Can easily be synchronized with a tunnel.
> Height adjustments to suit height variant bottles.
R-SLB Shrink wrapper Machine for bottles |
| Capacity | 40-50 BPM 50-100 BPM |
| Size L*W*H | 2100*850*2000mm |
| weight | 600Kgs |
| Powder supply | AC3-Phase 220/380V |
| Eligibility percent | ≥99.5% |
| Host machine powder | 1.5KW |
Shrink labels | Materials | PVC、PET、OPS |
| Thickness | 0.03~0.13mm |
| Labels Length | 40~100Mm |
| Flat width | Max100Mm |
| Inner Dia. Of Labels roll | 3”~10” adjustable |
Bottles Specs | Height | Max320mm |
| Diameter | Ø28- Ø125mm |
| Material | Glass、Metal 、Plastic |
| Shapes | Round , square, flat , curved cup-shaped bottles |
