PRODUCTION
With its wide range including various technical solu-tions, Ableplas production does not only include stan-dard machines, but also offers complete pipes extru-sion lines, tailor-made according to the customers’ requirements, still assuring high performances and competitive prices.
The lines can produce pipes in pvc ma-terials, with diameters starting from a few mm up to 63 mm.
MATERIALS AND APPLICATIONS:
PVC:
• cable conduit
- protection sheathing for electric cable
Main Characters: This line can solve the problems of high temperature melting, high viscosity, easy-decomposition. The special designed screw, gearbox, tooling, and HMI system make the line reliable and easy operation.
Main technical parameter:
Diameter(mm) | 16-40dual | 20-63dual | 20-63 |
Extruder mode | SJZ51/105 | SJZ65/132 | SJZ51/105 |
Extruder power | 18.5AC | 37AC | 18.5AC |
Max lineal speed | 10 | 15 | 15 |
Max capacity | 120 | 250 | 120 |
