Features&Function:
Function : Energy-saving , environmental protection
section of mesh , plastic sections, increase production
plastics, reducing the amount of manual labor for each
granulation enterprises to provide new energy efficiency .Technical
Parameters
Filter material : Imported special tool steel, surface
treatment , hardness of 68' , white steel or tungsten steel
Mesh size: 30, 40, 50, 60, 70, 80
Scraper material : Germany H13 , carbide welding
Box material : 55* casting steel material
Gearbox : Guotai GuoMao or Sanlian brand
Motor : 0.55kw
Electric box : lzone
Technical parameters |
Model | Mesh size | Mesh number | Applicable extruder | Applicable plastics | Hourly output | Motor power |
LN300 | Φ300mm | 5、10、15、20、30、40、50、60、70、80 | Φ120-Φ130 | PP、PE、PS、PC、ABS、PET、PA | 200kg-300kg | 0.55kw |
LN350 | Φ350mm | Φ140-Φ150 | 300kg-450kg | 0.75kw |
LN400 | Φ400mm | Φ160-Φ180 | 450kg-700kg | 1.5kw |
LN500 | Φ500mm | Φ190-Φ230 | 800kg-1000kg | 4.0kw |
