使用环境条件 | Environment Condition |
地点:室内 | Location:Indoors |
电源供应:无危险区域 | Power supply : No dangerous area |
电源:三相四线,380V/3P/50Hz | Power: 3-phase 4 wires structure,380V/3P/50Hz |
装机总功率:36KW | Total power:36KW |
平均能耗:20KW—25KW | Average energy consumption :20KW—25KW |
油泵电机功率:7.5KW | Oil pump motor power:7.5KW |
湿度:≤95% | Humidity degree:≤95% |
温度:0-35℃ | Temperature:0-35℃ |
冷却水要求:≤20℃, ≥0.3Mpa | Cooling water:≤20℃, ≥0.3Mpa |
冷却水用量:5T/H | Water consumption:5T/H |
气源压力:0.6Mpa | Air pressure:0.6Mpa |
气源排量:24m³/h | Air consumption:24m³/h |
使用物料:HDPE/PP | Suitable material:HDPE/PP |
制品规格:2L | Specifications about the product: Max container volume: 2L |
最大塑化能力:70kg/hr-80kg/h | The max. plasticizing capacity:70kg/hr-80kg/hr |
备注:挤出量根据加工物料和操作条件的不同可能有相应变化 | NOTE: The output varies according to the materials and the operation conditions. |
