Film Squeezing& Pelletizing dryer removes the water by screw pushing and electrical magnetic heating. The screw barrel is made of material feeding barrel, compressing barrel and plasticized barrel. After feeding, squeezing ,the film will be plasticized and cut to particle by the pelletizer which is installed besides the mold.
Name | Film Squeezing Dryer |
Model | LDJZ-300 | LDJZ-500 | LDJZ-1000 |
Capacity KG/H | 300 | 500 | 1000 |
Motor power KW | 55 | 75 | 110 |
Rotating speed
rpm | 87 | 87 | 87 |
Heating power KW | 15 | 25 | 40 |
Pelletizing power KW | 3 | 4 | 5.5 |
Pelletizing blade PCS | 3 | 3 | 4 |
Final moisture | 1-2% | 1-2% | 1-2% |
1 | Working efficient | Can remove the water of the washed film by screw washing |
2 | No stuck | Uniform feeding without stuck |
3 | Final moisture | 1-2% |
4 | Feeding to Granulating line | Be easier for feeding the film/woven-bag to Granulating line |
5 | Capacity | Improve the capacity of Granulating line in the next step |
