Blow Molding Machine 923 Favorites

Product Categories: Extrusion Blow Molding
Packaging Details:	Trademark:
Certification:
Payment Terms：
FOB:	HS Code:
Loading Port：GUANG ZHOU

FOSHAN BEKWELL INTELLIGENT EQUIPMENT CO.,LTD.
Company type： Manufacturer	Credit：
Main products：Blow Molding Machine

Get Quotation

Contact Supplier

To：	Jade Liang
Subject：
Message：	You can also enter 300 characters

Message has been sent successfully.

Post Buying Request

*Subject:
*Matching Rules:	Categories Keywords
*Inquiry Type:
*Keywords:	+ max five keywords
	Added:
	Note:you can add at least one keywod and most five keywords
*Categories:	Add Delete
*Detailed Description:
	Note: Please write your requirement in detail
Attachments：	+ Note: Attachments will help you get accurate solutions Note: Attachments can help you get accurate solution from suppliers
Max quotations want to receive：
	I agree to share my business card with quoted suppliers

Submit Inquiry

No matched supplier

Public souring

Your inquiry has been submitted successfully but 0 supplier matched at present, you will get quotations from Public Sourcing.

Close

Your inquiry has submited successfully and suppliers have been matched by LookingPlas,You will get the quotations as soon as possible.

Close

You had already registered,no need join again.

Registered successfully.

Sorry only Buyer can register the activities.

Model	Unit	BM30	BM50	BM100
Max product volume	L	30	50	100
Dry cycle	Pc/h	600	450	360
Die head structure	储料式Accumulating type
Main screw diameter	mm	80	90	100
Max plasticzing capactity(PE)	kg/h	120	180	190
Driving motor	Kw	37	45	55
Accumulating volume	L	5.2	6.2	12.8
Oil pump motor power	Kw	15	18.5	22
Clamping force	KN	280	400	600
Space between platen	mm	400-900	450-1200	500-1300
Platen size W*H	mm	740*740	880*880	1020*1000
Max mould size	mm	550*650	700*850	800*1200
Heating power of die head	Kw	20	28	30
Machine dimension LWH	m	4.32.23.5	5.62.43.8	5.52.54.0
Machine weight	T	12	13.5	16
Total power	Kw	95	110	135
