Model NO.:	HY-767-2
Round container size:	Diameter: φ10-100mm, Height: 30-260mm
Round container max. print area:	L 260 x W220mm
Oval container size:	R: 10-250mm, Height: 30-260mm
Oval container max. print area:	L 120 x W220mm
Drive:	Mechanical Driven
Control system:	OMRON PLC & Touch Screen
Max. printing capacity:	70 pcs/min
Registration tolerance:	+/- 0.2 mm
Infeed conveyor:	1 unit, length: 2 meters
Deionizing device:	1 unit
Flame treating system:	1 unit, LP gas
Motor:	ITALY SITI
Print head:	1 unit
UV system:	1 unit intelligent UV system, 5KW per each
Outfeed conveyor:	1 unit, Length: 2 meters
Frequency Converter:	OMRON
Pneumatic parts:	FESTO or SMC
Electrical:	380V 3phase 50Hz
Air requirement:	5-7 bar
Air consumption:	85 liter/ minute max. (per color)
Power consumption:	5.4 KW/color x 2
Machine size(LxWxH):	Main machine: (2300x1800x1700mm) x 2
Weight:	1600 KG x 2
