Product Categories: Extrusion Blow Molding
Packaging Details:	Trademark:
Certification: CE, ISO9001:2008, QS,
Payment Terms： L/C,
FOB: USD $/Set	HS Code:
Loading Port：

GuangdongLeshanIntelligentEquipmentCorp.,Ltd
Company type： Manufacturer	Credit：
Main products：ExtrusionBlowMoldingMachine

Get Quotation

Model	S2-200+02-85-8
Cooling System Pressure	0.4Mpa
Max. Blow Volume	0.5L
Pneumatic System Rated Working Pressure	0.8Mpa
Platform Lifting Motor Rated Power	1.5kW
Barrel Heating Power	10.4kW
Max Extrusion Capacity	130kg/h
Die Head Heating Zone	17
Number of Station	2
Head Lifting Motor Rated Power	2.2kW
Extruder Rotating Speed	20-66r/min
Clamping Force	200kN
Extruder Length/Diameter Ratio	24
Clamping Distance of Mold	250mm
Hot Cutter Power	2kW
Barrel Heating Zone	3
Extruder Motor Power	30kW
Blow Pin Motor Rated Power	3kW/3kW
Carriage Motor Rated Power	5.5kW/5.5kW
Mold Clamping Motor Rated Power	7.5kW/7.5kW
Carriage Stroke	750mm
Number of Die Head	8
Die Head Heating Power	8.5kW
Extruder Diameter	85mm
Total Power	87.32kW
Material	HDPE,PP
