HDPE Plastic Geomembrane waterproof Sheet Making Machine production line,
Main features of the Modified Bitumen Waterproofing Membrane Production Line
1) Manufacturing Capacity:
Annually manufacturing 10,000,000 m2of various types of modified bitumen waterproofing membrane, as per three shifts per day, 20 hours per working day, 300 days per year, calculated on basis of 3 mm thick membrane.
2) Speed of the production line: 0~30m/min, adjustable. On the basis of producing 3mm membrane.
3) Mechanical speed: 35 m/min.
4) Voltage (according to the voltage in Buyer's country)
HDPE Plastic Geomembrane waterproof Sheet Making Machine production line Introduction:
The geomembrane equipment mainly consists of extruder, a quick change screen device, head die, a double air outlet ring, a tractor, a coiler, and temperature and electrical control systems.
1. Using special extruder, special screw and geomembrane equipment to enhance plasticizing capacity and increase production. It is moved by the whole machine and is easy to adjust.
2. The special screw head, both the greenhouse film and the geomembrane performance can not only produce greenhouse film, but also produce geomembrane.
3. It adopts hydraulic quick stop screen changing device, which is fast and convenient.
4. Adopting advanced foreign technology, introducing internal cooling control system and double air vent ring; easy to control cooling air volume and improve cooling effect
Waterproofing Membrane Sheet Production Line information:
Product thickness: 1-20mm
Product width: 1000- 8000mm
Line speed: 0-8m/min
controlling temperature: ≤200℃
