JIC720D Double Color PVC Air Blowing Molding Machine (Miss star +8615880812025)
Features
1.The double color PVC air blow molding machine is suitable for producing double color PVC sandals.
2. PLC control, human interface, simple operation screen.
3.The machine is easy and safe to operate with what you don't need from professionals. Both the pressure and the flow can be adjusted, making the operation of the machine more convenient and reasonable, and making the quality of the products more stable.
4.The double color PVC air blow molding machine with its large injection capacity and large clamping force ensures the quality of the products.
5.With the switch nozzle, it is possible to save the time cycle and produce more sandals.
6. Proportional double control and adjustable speed, the amount of feed and pressure constantly ensure product quality.
7.The blow molding machine can be manufactured according to customers' requirements.
Parameters:
Project | Unit | Specifications |
Model |
| 720D | 724D |
Raw Material |
| PVC | PVC |
Work station number | station | 20 | 24 |
Clamping force | T | 80 | 80 |
Mould Height | mm | 50-300 | 50-300 |
Screw Diameter | mm | ¢70,¢60 | ¢70,¢60 |
Screw Speed | r.p.m | 0-150 | 0-150 |
Injection capacity(max) | cm3/cc | 770,565 | 770,565 |
Injection Pressure | kg/c㎡ | 0-120 | 0-120 |
Motor Power | kw | 18.5,15 | 18.5,15 |
Heating Power | kw | 13,11 | 13,11 |
Limit of temperature | point | 4 | 4 |
Mold Size（max) | mm | 400*220*300 | 400*220*300 |
Machine Size | mm | 8200*7550*2650 | 8200*7550*2650 |
Machine weight | kg | 14000 | 14500 |
