Model
|
DS75S |
DS110S |
DS125S |
| Pipe Diameter |
20mm – 75mm |
32mm – 110mm |
32mm – 125mm |
| Pipe Length |
3m - 6m |
3m - 6m |
3m - 6m |
| Oven |
Contact heating by Aluminum block，Stainless steel heating tube |
Contact heating by Aluminum block，Stainless steel heating tube |
Contact heating by Aluminum block/Oven heating with pipe rotary |
| Heating Power |
5KW |
10KW |
10KW |
| Compressed air pressure |
0.4Mpa |
0.6Mpa |
0.6Mpa |
| U-type |
Pushing the mould into pipe directly |
Pushing the mould into pipe directly |
Pushing the mould into pipe directly |
| Cooling type |
Water – cooling or Air-cooling |
Water – cooling or Air-cooling |
Water - cooling |
| Machine speed |
18S to 60S |
20S to 60S |
20S to 60S |
| Mould material |
U-type：45# steel with Cr electroplating |
U-type：45# steel with Cr electroplating |
U-type：45# steel with Cr electroplating R-type：The collapsible parts are 3Cr13 and 40Cr, other parts 45# steel with Cr electro-plating |
| Machine type |
Automatic, double line, two pipes per cycle 4 heating station and 2 belling station |
Automatic, Double line, two pipes per cycle 4 heating station and 2 belling station |
Automatic, Double line, two pipes per cycle 4 heating station and 2 belling station |
| Total power |
7KW |
15KW |
15KW |
| Machine weight |
2400kg |
2700kg |
2700kg |
| Machine dimension |
7000mm(L)×1950mm(W)×1900mm(H) 1*40GP |
7700mm(L)×1800mm(W)×1500mm(H) 1*40GP |
7700mm(L)×1800mm(W)×1500mm(H) 1*40GP |
