Model
|
DS160-NI |
DS250-NI |
DS315-NI |
DS400-NI |
DS630-NI |
Model |
DS160-NI |
DS250-NI |
DS315-NI |
DS400-NI |
DS630-NI |
Pipe Diameter |
40mm – 160mm |
50mm - 250mm |
110mm - 315mm |
160mm - 400mm |
315mm - 630mm |
Pipe Length |
3m - 6m |
3m - 6m |
3m - 6m |
3m - 6m |
3m - 6m |
Oven |
One heating oven, semi-enclosed heated,Ceramic heating plate and Stainless steel heating tube |
One heating oven, semi-enclosed heated,Ceramic heating plate and Stainless steel heating tube |
One heating oven, semi-enclosed heated,Ceramic heating plate and Stainless steel heating tube |
One heating oven, semi-enclosed heated,Ceramic heating plate and Stainless steel heating tube |
One heating oven, semi-enclosed heated,Ceramic heating plate and Stainless steel heating tube |
Pipe Rotary |
Clockwise and anti-clockwise |
Clockwise and anti-clockwise |
Clockwise and anti-clockwise |
Clockwise and anti-clockwise |
Clockwise and anti-clockwise |
Heating Power |
10KW |
11KW |
16.5KW |
23KW |
42KW |
Compressed air pressure |
0.6Mpa |
0.6Mpa |
0.6Mpa |
0.6Mpa |
0.6Mpa |
Water pressure |
0.4Mpa |
0.4Mpa |
0.4Mpa |
0.4Mpa |
0.4Mpa |
Hydraulic pressure |
6.3Mpa |
6.3Mpa |
6.3Mpa |
6.3Mpa |
8.0MPa |
U-type |
Pushing the mould into pipe directly |
Pushing the mould into pipe directly |
Pushing the mould into pipe directly |
Pushing the mould into pipe directly |
Pushing the mould into pipe directly |
R-type |
With ext - pressure and collapsible mandrel |
With ext - pressure and collapsible mandrel |
With ext - pressure and collapsible mandrel |
With ext - pressure and collapsible mandrel |
With ext - pressure and collapsible mandrel |
Cooling type |
Water - cooling |
Water - cooling |
Water - cooling |
Water - cooling |
Water - cooling |
Machine speed |
45S to 160S |
50S to 150S |
60S to 200S |
80S to 300S |
200S to 1200S |
Mould material |
U-type:45# steel with Cr electroplating R-type:The collapsible parts are 3Cr13 and 40Cr, other parts 45# steel with Cr electro-plating |
U-type:45# steel with Cr electroplating R-type:The collapsible parts are 3Cr13 and 40Cr, other parts 45# steel with Cr electro-plating |
U-type:45# steel with Cr electroplating R-type:The collapsible parts are 3Cr13 and 40Cr, other parts 45# steel with Cr electro-plating |
U-type:45# steel with Cr electroplating R-type:The collapsible parts are 3Cr13 and 40Cr, other parts 45# steel with Cr electro-plating |
U-type:45# steel with Cr electroplating R-type:The collapsible parts are 3Cr13 and 40Cr, other parts 45# steel with Cr electro-plating |
Total power |
13KW |
15.5KW |
25KW |
30KW |
55KW |
Machine weight |
2200kg |
2300kg |
2800kg |
3000KG |
4500KG |
Machine dimension |
7000mm(L)×1530mm(W)×1920mm(H) 1*20GP |
7300mm(L)×1660mm(W)×1950mm(H) 1*20GP |
7550mm(L)×1850mm(W)×1950mm(H) 1*40GP |
7900mm(L)×2140mm(W)×2125mm(H) 1*40GP |
8450mm(L)×2970mm(W)×2250mm(H) 2*40GP |
