CN260-DMPET PET Preform Injection Molding Machine 645 Favorites

Product Categories: Up to 100T Injection Machine
Packaging Details:	Trademark:ACNOVO
Certification: ISO9001:2008,
Payment Terms： L/C, T/T,
FOB: USD $26400/	HS Code: 84771010
Loading Port：

NINGBO ACNOVO SMART DEVICE CO., LTD.
Company type： Manufacturer	Credit：
Main products：Injection molding machine

Get Quotation

Contact Supplier

To：	Bill
Subject：
Message：	You can also enter 300 characters

Message has been sent successfully.

Post Buying Request

*Subject:
*Matching Rules:	Categories Keywords
*Inquiry Type:
*Keywords:	+ max five keywords
	Added:
	Note:you can add at least one keywod and most five keywords
*Categories:	Add Delete
*Detailed Description:
	Note: Please write your requirement in detail
Attachments：	+ Note: Attachments will help you get accurate solutions Note: Attachments can help you get accurate solution from suppliers
Max quotations want to receive：
	I agree to share my business card with quoted suppliers

Submit Inquiry

No matched supplier

Public souring

Your inquiry has been submitted successfully but 0 supplier matched at present, you will get quotations from Public Sourcing.

Close

Your inquiry has submited successfully and suppliers have been matched by LookingPlas,You will get the quotations as soon as possible.

Close

You had already registered,no need join again.

Registered successfully.

Sorry only Buyer can register the activities.

CN-DM技术规格参数表 Specifications
说明	DESCRIPTION	UNTT	CN260-DMPET
国际公认型号	International size rating
注射装置	INJECTION UNIT		A	A+
螺杆直径	Screw diameter	mm	55	60
螺杆长径比	Screw L/D ratio	L/D	25	25
理论注塑容量	Shot Volume	cm3	594	650
注射重量	Injection weight(PS)	G/克	604	654
注射重量	Injection weight(PS)	OZ/盎司	21.3	23.1
注射速率	Injection rate	g/s	213	277
注射压力	Injection pressure	Mpa	165	151
螺杆转速	Screw speed	rpm	0-200
合模装置	CLAMPING UNIT
合模力	Clamping force	KN	2600
移模行程	Toggle stroke	mm	490
拉杆內距	Space between tie bars	mm	575×525
容模量	Mold thickness(Min-Max)	mm	180-580
顶出行程	Ejector stroke	mm	160
顶出力	Ejector force	KN	77
其它	OTHERS
最大油泵压力	Max.pump pressure	Mpa	16
油泵马达功率	Pump motor power	KW	37
电热功率	Heater powre	KW	17
机械外形尺寸	Machine dimension	m	6.2×1.6×2.0
