16mm-63mm pe pipe machine
With over 20 years of experience in the plastic extrusion machinery sector, China Comrise has honed its expertise in the field of 16mm-63mm pe pipe machine. This experience has been instrumental in making the company one of the best in the market. In this article, we will delve into why China Comrise is considered one of the best 16mm-63mm pe pipe machine manufacturers in the market.
Product description
Are you on the lookout for a high-quality and efficient 16mm-63mm pe pipe machine? Look no further because our product has got you covered! Comrise advanced 16mm-63mm pe pipe machine is designed with precision and care to provide a maximum output with high efficiency and faster line speed.
Comrise easy maintainable 16mm-63mm pe pipe machine is made from high-quality materials, ensuring that our products are not only strong but also made to last. The high-quality material used guarantees that the products produced from our machine are durable, making our machine a valuable asset for any business.
China Comrise 16mm-63mm pe pipe machine is also highly efficient. This means that there is minimal energy wastage, reducing operating costs and making it an eco-friendly option. With fast line speed, you can produce a larger volume of pipes in shorter amounts of time, making it a great investment for businesses looking to increase their productivity.
The weight per meter for HDPE hdpe pe ppr pipe extrusion machine line
|
HDPE water supply pipe weight meter
|
|
OD
mm
|
SDR26
|
SDR21
|
SDR17
|
SDR13.6
|
SDR11
|
|
pressure Mpa
|
|
0.6
|
0.8
|
1.0
|
1.25
|
1.6
|
|
thickness
|
weight/m |
thickness |
weight/m |
thickness |
weight/m |
thickness |
weight/m |
thickness |
weight/m
|
|
φ20
|
|
|
1.2
|
0.068
|
1.5
|
0.084
|
1.8
|
0.099
|
2.3
|
0.123
|
|
φ25
|
|
|
1.4
|
0.100
|
1.8
|
0.126
|
2.2
|
0.151
|
2.3
|
0.157
|
|
φ32
|
1.2
|
0.111
|
1.5
|
0.138
|
1.9
|
0.172
|
2.4
|
0.214
|
3
|
0.262
|
|
φ40
|
1.4
|
0.163
|
1.9
|
0.218
|
2.3
|
0.262
|
2.9
|
0.324
|
3.7
|
0.405
|
|
φ50
|
1.8
|
0.262
|
2.3
|
0.331
|
2.9
|
0.412
|
3.7
|
0.517
|
4.6
|
0.630
|
|
φ63
|
2.2
|
0.403
|
3.0
|
0.543
|
3.7
|
0.662
|
4.7
|
0.826
|
5.8
|
1.001
|
|
φ75
|
2.6
|
0.558
|
3.5
|
0.755
|
4.5
|
0.957
|
5.6
|
1.172
|
6.8
|
1.299
|
|
φ90
|
3.2
|
0.838
|
4.3
|
1.111
|
5.4
|
1.378
|
6.7
|
1.683
|
8.2
|
2.023
|
|
φ110
|
4.2
|
1.340
|
5.3
|
1.574
|
6.6
|
2.058
|
8.1
|
2.489
|
10.0
|
3.016
|
|
φ125
|
4.8
|
1.740
|
6.0
|
2.153
|
7.4
|
2.625
|
9.2
|
3.213
|
11.4
|
3.906
|
|
φ140
|
5.4
|
2.192
|
6.7
|
2.694
|
8.3
|
3.297
|
10.3
|
4.029
|
12.7
|
4.876
|
|
φ160
|
6.2
|
2.876
|
7.7
|
3.537
|
9.5
|
4.312
|
11.8
|
5.274
|
14.6
|
6.402
|
|
φ180
|
6.9
|
3.602
|
8.6
|
4.446
|
10.7
|
5.453
|
13.3
|
6.687
|
16.4
|
8.098
|
|
φ200
|
7.7
|
4.466
|
9.6
|
5.513
|
11.9
|
6.751
|
14.7
|
8.216
|
18.2
|
9.979
|
|
φ225
|
8.7
|
5.644
|
10.8
|
6.977
|
13.4
|
8.651
|
16.6
|
10.433
|
20.5
|
12.643
|
|
φ250
|
9.6
|
6.960
|
11.9
|
8.545
|
14.8
|
10.498
|
18.4
|
12.852
|
22.7
|
15.561
|
|
φ280
|
10.7
|
8.690
|
13.4
|
10.774
|
16.6
|
13.187
|
20.6
|
16.116
|
25.4
|
19.503
|
|
φ315
|
12.1
|
11.054
|
15.0
|
13.572
|
18.7
|
16.711
|
23.2
|
20.417
|
28.6
|
24.703
|
|
φ355
|
13.6
|
14.003
|
16.9
|
17.233
|
21.1
|
21.248
|
26.1
|
25.889
|
32.2
|
31.348
|
|
φ400
|
15.3
|
17.751
|
19.1
|
21.941
|
23.7
|
26.897
|
29.4
|
32.860
|
36.3
|
39.817
|
|
φ450
|
17.2
|
22.451
|
21.5
|
27.834
|
26.7
|
34.086
|
33.1
|
41.618
|
40.9
|
50.463
|
|
φ500
|
19.1
|
27.702
|
23.9
|
34.317
|
29.7
|
42.126
|
36.8
|
51.408
|
45.4
|
62.245
|
|
φ560
|
21.4
|
34.761
|
26.7
|
42.944
|
33.2
|
52.747
|
41.2
|
64.464
|
50.8
|
78.013
|
|
φ630
|
24.1
|
44.039
|
30.0
|
54.286
|
37.4
|
66.842
|
46.3
|
81.506
|
57.2
|
98.818
|
|
φ710
|
27.2
|
56.012
|
33.9
|
69.124
|
42.1
|
84.803
|
52.2
|
103.557
|
64.5
|
125.741
|
|
φ800
|
30.6
|
71.005
|
38.1
|
87.547
|
47.4
|
107.587
|
58.8
|
121.441
|
72.6
|
159.466
|
PE water supply pipe standard-(GB/T 13663-2000)
This standard specifies the product specifications, technical requirements, test methods, inspection rules, marking, packaging, transportation, Storage. This standard also specifies basic performance requirements for raw materials, including a classification system.
This standard applies to water supply pipes made of PE63, PE 80 and PE 100 materials. The nominal pressure of the pipe is 0.32MPa~1.6MPa, and the nominal outer diameter is 16 mm~1000 mm.
The pipes specified in this standard are suitable for general-purpose pressure water transmission at temperatures not exceeding 40C, as well as for the transportation of drinking water.
Why is HDPE used for hdpe pe ppr pipe ?
High-density polyethylene (HDPE) pipes are effective for the large scale transfer of liquids given that they can withstand high amounts of pressure and are unaffected by rust due to their thermoplastic quality. Unlike traditional metal pipe fittings, HDPE pipes do not rust, corrode or rot.
