3PE Anti Corrosion Coating Pipe Production Line
COMRISE’s 90-2000mm HDPE Thermal Insulation Pipe Machine commitment to quality is evident advantages that come with using its plastic pipe machines. 90-2000mm HDPE Thermal Insulation Pipe Machine offer high production capacity, which translates to faster turnaround times and increased efficiency. 90-2000mm HDPE Thermal Insulation Pipe Machine are also very user-friendly, with easy-to-use controls that allow for quick adjustments and minimum errors. Additionally, COMRISE’s after-sale service is top-notch, with a team of experts on standby to provide you with technical assistance if needed.
Introducing the 90-2000mm HDPE Thermal Insulation Pipe Machine, an industrial solution designed for producing top-quality PE anticorrosion and insulation pipes. As a China-based supplier and manufacturer for 90-2000mm HDPE Thermal Insulation Pipe Machine, COMRISE takes pride in its ability to manufacture cutting-edge plastic pipe machines, including HDPE water pipe machines and winding pipe machines, that boast high quality, high output, stable production, and excellent after-sale services.
3PE Anti Corrosion Coating Pipe Production Line Process Flow:
The outer wall of the steel pipe is first derusted to clean the rust on the surface of the steel pipe, and then the steel pipe is transported to the intermediate frequency heating place for heating through a spiral conveyor line. After the steel pipe is heated, it is sprayed with epoxy powder, wrapped with adhesive and polyethylene, and the wrapped steel pipe is Then cooling spray is performed to reduce the temperature, and finally both ends of the steel pipe are beveled and polished.
The 3PE Anti Corrosion Coating Pipe Production Line outer anti-corrosion layer of 3PE steel pipe is an anti-corrosion structure composed of a bottom layer of epoxy powder, an intermediate layer of adhesive, and an outer layer of polyethylene. 3PE Anti Corrosion Coating Pipe Production Line has high mechanical strength, excellent electrical insulation properties, a high degree of mechanization of the production line, and relatively stable process parameters. With the advantages of not polluting the environment, 3PE Anti Corrosion Coating Pipe has been widely used in major pipeline anti-corrosion projects in China in recent years. The three-layer structure polyethylene anti-corrosion layer combines the excellent properties of epoxy coating and extruded polyethylene anti-corrosion layer, combining the interface properties and chemical resistance properties of the epoxy coating with the mechanical protection properties of the extruded polyethylene anti-corrosion layer These advantages are combined to significantly improve their respective performance. Therefore, 3PE Anti Corrosion Coating Pipe is very superior as an outer protective layer for buried pipelines. According to relevant information, three layers of PE can extend the service life of buried pipelines to 50 years. Currently, it is considered an excellent external anti-corrosion technology for pipelines. In our country, 3PE Anti Corrosion Coating Pipe has been first used in oil and gas systems.
3PE Anti Corrosion Coating Pipe Production Line generally consists of 3 layers of structure:
The first layer of epoxy powder (FBE>100um)
The second layer of adhesive (AD)170~250um
The third layer of polyethylene (PE) 2.5~3.7mm
The 3PE Anti Corrosion Coating Pipe Production Line is an anti-corrosion structure composed of a bottom layer of epoxy powder, an intermediate layer of adhesive, and an outer layer of polyethylene. 3PE Anti Corrosion Coating Pipe Production Line has strong corrosion resistance, high mechanical strength, excellent electrical insulation properties, a high degree of mechanization and technology. The 3PE Anti Corrosion Coating Pipe Production Line parameters are relatively stable and it does not pollute the environment. 3PE Anti Corrosion Coating Pipe has been widely used in pipeline anti-corrosion projects at home and abroad.
