Technical Parameters:
1. Temperature range: room temperature~ 600℃
2. Temperature resolution: 0.001℃
3. Temperature fluctuation: ±0.01℃
4. Temperature repeatability: ±0.1℃
5. Heating rate: 0.1～100℃/min
6. Cooling rate: 0.1~20℃/min
7. Constant temperature time: program setting ≤ 24h
8. Curve scan: heating scan, cooling scan
9. DSC range: 0～±800mW
10. DSC resolution: 0.01uW
11. DSC accuracy: 0.001mW
12. Temperature control mode: heating, constant temperature, cooling
13. Working power supply: AC220V/50Hz or customized
14. Atmosphere control gas: nitrogen, oxygen (automatic switching of the instrument)
15. Gas flow: 0-300mL/min
16. Gas pressure: 0.3MPa
17. Display mode: 24bit color, 7-inch LCD touch screen display
18. Data interface: standard USB interface
19. Parameter standard: equipped with standard substances (indium, tin, lead), users can correct the temperature by themselves
20. The instrument has multiple sets of thermocouples, a set of test sample temperature, and a set of test instrument internal ambient temperature
21. Software with automatic analysis function
22. Multi-stage temperature rise and fall test, five-stage program setting
Technical Features:
1. Industrial-grade 7-inch touch screen with rich display information.
2. New metal furnace body structure, better baseline and higher precision. The heating adopts the indirect conduction method, which has high uniformity and stability, and reduces pulse radiation, which is better than the traditional heating mode.
3. USB communication interface, strong versatility, reliable and uninterrupted communication, supports self-recovery connection function.
4. Automatic switching of two air flow rates, fast switching speed and short stabilization time. At the same time, add a protective gas input.
5. The software is simple and easy to operate.
Furnace structure:
