PVC double pipe production line
XinDa Plastic Machinery Co.,Ltd www.xindasj.com
1. Introduction:
(1) The main machine is SJSZ51/105 or SJSZ65/132 conical double-screw extruder
(2) It avoids a waste condition when one tube is adjusted and the other one is affected.
(3) The diameter of the extruded pipe is from Φ20-Φ63. It can fully use the extruding capacity of the extruder.
(4) Even if it produces small diameter pipe, it can get great output, too.



2. Technical data:
Pipe range | 16-40mm | 16-63mm |
Extruder | SJZ51/105 | SJZ65/132 |
Extruder power | 18.5kw | 37kw |
Extrusion capacity | 120kg/h | 250kg/h |
Max. Production speed | 2 x 8m/min | 2 x 10m/min |
