Melon seeds, peanuts packing machine, automatic packing machine
Main features：
1、High precision digital sensor, equipped with four buckets, so that accurate measurement can be achieved instantaneously;
2、Microcomputer control system, the use of double vibration, advanced technology, easy to operate;
3、Measuring bucket is easy to assemble and disassemble, quick and easy, easy to clean and maintain.
4、 low input, high return, high speed, high efficiency.
5 、imported PLC full computer control system, man-machine interface, large display touch screen, easy to operate.
6、 servo system, horizontal seal pneumatic control, accurate positioning, excellent performance, the maximum limit of improving the reliability and intelligence of the whole machine.
7、The machine and metering device to be matched automatic completion of feeding, measuring, filling, bag making, date printing, inflatable and exhaust), counting, finished product output full packaging process.
Main technical parameters：
Item | Content |
Capacity |
50 bags/min,it is according to quality of film and packing products. |
Accuracy | ≤±4g |
Bag size | (L)60-300mm (W)90-200mm |
Film width | 420mm |
Bag type |
Pack with film, top seal, bottom seal and back seal by automatic bag making machine. |
Film thickness |
0.06-0.08mm, the best is 0.07-0.08mm |
Package material |
thermal composite material., likeBOPP/CPP, PET/AL/PE etc |
Air consumption | 0.8Mpa 0.5m3/min |
Total powder | 4.495KW |
Voltage |
Four wire three phase, 380V 50HZ |
Air compressor |
Not less than 1 cube |
Total height |
3100m |
Packing range: This machine is suitable for packaging requires precise measurement of particle packing such as: pistachio, cashew nuts, beans, melon seeds, peanuts, Q sugar, washing powder, grains, sesame, seed, coffee beans and so on a variety of materials
Sample:
Packing：
