1. Double station, six cavities.
2. Fully automatic.Auto deflashing.
3. Special design of mold
4. First technology in China
Fetures of seaballs blow molding machine QJB505D
1. Double station, Up to six cavities.
2. Fully automatic.
3. Auto deflashing.
4. Balls can fall off automaticly.
5. Special designed of mold
6. First technology in China so far.
7. Can save a lot of labor cost.
Specification:
Parameter | Unit | QJ50D | QJ65D |
Material | / | PP,PE etc | PP,PE etc |
Max. Product Volume | L | 2 | 5 |
Productive Capacity | Pcs/hr | 1000*2 | 800*2 |
Die Number | set | 1234 | 1234 |
Dimension | mm | 2700*2000*2500 | 3400*2200*2600 |
Weight | Ton | 4 | 6.5 |
Clamping force | KN | 38 | 68 |
platen opening stroke | mm | 130-370 | 150-500 |
platen size | mm | 280*370 | 320*370 |
Max mould size | mm | 350*370/205*600 | 350*370/238*600 |
Mould thickness | mm | 135-210 | 153-300 |
Heating Zone Number | Part | 3-5 | 3-5 |
Die diameter | mm | 75 | 135 |
Center distance of twin-die | mm | 130 | 160 |
Center distance of tri-die | mm | 85 | 110 |
Center distance of four-die | mm | 65 | 85 |
Screw diameter | mm | 55 | 70 |
Screw L/D ratio | L/D | 24:1 | 24:1 |
Extrusion Capacity | Kg/hr | 60-80 | 100-120 |
Power | kw | 15 | 23 |
Voltage | V | 220-380 | 220-380 |
Frequency | HZ | 50-60 | 50-60 |
Note: Due to continual improvement, specifications are subject to change without notification. Please refer to the latest actual machine.
We will even send an engineer to your country to help set up the machine.
