The whole machine uses SS304 which has the feature of perfect anti-corrosion. The organic glass cover can prevent the flowing of dust which is more environmental friendly.

1. Capacity: ≤60 p/min （Single Pouch）; ≤120 p/min （Double Pouches）

2. Pouch size: single pouch 80*100 mm (min); 180*220 mm (max)

double pouches (60+60)*70mm (min); (90+90)*220mm (max)

3. Volume: 400g (single pouch); 100g (double pouches)

4. Precision: ±1%

5. Roll ID: φ70-80mm

6. Roll OD: ≤φ500mm

7. Power Source: 3 phase AC 380V, 50HZ

8. Power: 5.5KW

9. Weight: about 2500KG

10. Dimension: 3495*1000*1550 (Dust-free hose + 60)mm (L*W*H)
