Application & Features
This series can release water molecule from raw materials with heat after fricton through high speed rotating with double functions in effective drying and evermixing.It is particularly suitable for drying and mixing powder,crushed or water washing ervycling materials;
Easily discharge material without starting motor.
With such functions as automatic temperature control.timing,overload protection,
Double layer stainless steel heat preserving barrel,the Blades,baffle and barrel cover are made of stainless steel
The bottom of barrelbody applies taper design without dead corner profile Stagered Blades,the materials can Mixed friction faster,motor has higher utilization rate,and the barrel can be cleaned easily.
Has the inertial wheel to be designed, it can crush the material which is agglomerates.
Specifications
Model | Total Volume(L) | Mixingcapacity | Motorpower (KW) | Rotaryspeed (r/min) | Appearancesize (mm) | Weight |
JCGH25p | 60 | 25 | 4 | 500 | 1000*750*1100 | 100 |
JCGH50p | 125 | 50 | 7.5 | 500 | 1100*800*1300 | 230 |
JCGH100p | 250 | 100 | 15 | 500 | 1200*950*1400 | 400 |
JCGH150p | 375 | 150 | 22 | 500 | 1400*1050*1500 | 550 |
JCGH200p | 500 | 200 | 37 | 500 | 1750*1300*1700 | 700 |
