machine feature:
1: linear guide support single frame, finite element analysis of the design, to ensure adequate clamping force, not up mode.
2: Large opening stroke, central locking force equilibrium, no deformation.
3: high accuracy without the fusion line storage type die head, easy to change color, with servo wall thickness control system, improve product quality, reduce production costs.
4:optional with multi function under blowing mechanism, automatic machine to take the product of a variety of auxiliary device, realize the production under blowing mechanism, automatic machine to take the product of a auxiliary device realize the production process is highly automated.
5: the whole system is equipped with safety protection grating, to ensure the safety of the production process without accident.
Technical Specification
Specification | units | BT120 | BT120L | BT120XL | BT120XXL |
Material |
| PE.PP.ABS | PE.PP.ABS | PE.PP.ABS | PE.PP.ABS |
Max. Container capacity | L | 250 | 350 | 500 | 1000 |
Screw diameter | MM | Φ120 | Φ120 | Φ120 | Φ120 |
Clamping force | KN | 700 | 1000 | 1500 | 2000 |
Platen Size | MM | 1200*1600 | 1400*1800 | 1800*2000 | 2000*2600 |
Max. Mold dimension (W x H) | MM | 800*1600 | 1000*1800 | 1500*2000 | 1800*2600 |
Platen opening stroke | MM | 600-1400 | 600-1400 | 800-1600 | 800-2000 |
Max. driver | KW | 115 | 120 | 177 | 199 |
Max.total power | KW | 155 | 180 | 245 | 271 |
Average energy consumption | KW | 50 | 60 | 75 | 95 |
Motor power of oil pump | KW | 30 | 37 | 22-30 | 30-37 |
Plasticizing capacity | KG/HR | 250 | 280 | 350 | 450 |
Extruder driving power | KW | 75 | 90 | 110 | 132 |
Accumulator capacity | L | 25 | 30 | 40 | 55 |
