1.In 85U+S2X8.5G automatic blow molding machines, the screw diameter is 85 mm and center distance is 80 mm
2. It features eight-die head, double station, single layer and high production output.
3. Equipped with scissors toggle clamping system, molding clamping is of high rigidity, and the clamping force is extremely large and uniform.
4. With high accuracy linear guide rail, this 85U+S2X8.5G is with fast moving speed and stable production.
5. Power consumption is decreased due to double-pump and proportion flow valve. Besides, this automatic blow molding machines adopt automatic lubrication system.
6. It is configured with thickness control system and auto-scraper.
7. It could be optional configured with telemaintenance system
1. General Features
| Carriage Horizontal Shuttle Stroke | mm | 750 |
| Clamp Force | kN | 94 |
| Air Pressure to Machine | bar | 6-8 |
| Air Consumption (Estimated) | m3 / hr | 5 |
| Minimum Pressure for Cooling Water to Machine | Mpa | 0.2 |
| Power of Pump Motor for Hydraulic Movements | kW | 11 |
| Power of Servo Pump Motor | kW | 5.5 |
| Power of Die Head Heating | kW | 13 |
| Power of Knife | kW | 2 |
| Total Power Installed (Estimated, Maximum) | kW | 55.8 |
2. Extruders
| Screw Diameter | mm | 65 | 45 | 45 |
| Type | / | 24 | 24D | 24D |
| Power of Electric Motor | kW | 15 | 15 | 15 |
| Power of Cooling Fan | kW | 0.3 | 0.2 | 0.2 |
| Power of Barrel Heating | kW | 9 | 5.5 | 5.5 |
| Max. Throughput = PE | kg/h | 60 | 15 | 15 |
| Max. Throughput = PP | kg/h | 42 | 4.5 | 4.5 |
3. Mould Dimensions
| Maximum Width | A | mm | 600 |  |
| Maximum Length | B | mm | 340 |
| Minimum Depth | C | mm | 125 |
| Clamp Open Max. Daylight | D | mm | 450 |
| Open Stroke | E | mm | 200 |
| Max Weight of Mould |
| kg | 100 |
4. Production Possibilities
| Cavities |
| 8 |
| Max. Center Distance | mm | 80 |
| Max. Container Width | mm | 70 |
| Max. Container Height | mm | 220 |
| Max. Container Depth | mm | 135 |
| Container Capacity (Estimated) | ml | 500 |
5. Machine Dimensions
| Maximum Width | mm | 4930 |
| Maximum Length | mm | 4200 |
| Maximum Height | mm | 2830 |
| Total Weight | kg | 9000 |
We provide one year equipment warranty, free installation for domestic market, for charging debugging in oversea market and all-life services. Equipment parts are free replacement for one year except for the rapid wear parts
