Features
Ideal solutions for medium output production needs.
1. EPET1.5-4H injection molding machine is operated user-friendly PLC system.
2. Molding change is fast.
3. Preform positioning is performed by servo motor.
4. This machine is ideal choice for medium output production needs.
5. Energy saving servo control is adopted not only to accomplish high-speed mold open/close but also to save 30% energy compare to similar machines manufactured by other factories.
6. This injection molding machine is adopts three-plates self locking to ensure fast clamping and strong claming force.
7. The heating box structure is designed at 6 adjusted zone, meeting different heating requirements for different tube length.
8. With stable pneumatic system, its buffer device works well and smoothly, without generating load noise.
9. It is controlled by all electric servo motor, avoiding the hydraulic oil leakage and contamination of the product.
10. It has 4 cavities and the maximum blow volume is 1.5 L.
Technical Specifications
EPET1.5-4H Injection Molding Machine
| Molding Specification | Output (Basic on 0.6 L Bottle) | bph | 5000 |
| Clamping Force | kN | 480 |
| Max. Mold Stroke | mm | 120 |
| Mold Thickness | mm | 190 |
| Max. Mold Size (H × W) | mm | 4.5 × 412 |
| Stretching Stroke | mm | 400 |
| Bottom Stroke | mm | 50 |
| Cavity Distance | mm | 101.6 |
| Number of Cavities | / | 4 |
| Bottle Specification | Max. Bottle Capacity | L | 1.5 |
| Neck Diameter Range | mm | 30-42 |
| Bottle Diameter | mm | 96 |
| Bottle Height | mm | 320 |
| Electrisify Specification | Heating Power | kW | 76 |
| Preform Feeding Motor | kW | 0.25 |
| Rotating Motor | kW | 0.12 |
| Revolution Motor | kW | 1.5 |
| Clamping Motor | kW | 3 |
| Total Power | kW | 86 |
| Actual Power Consumption | kW | ≤ 36 |
| Air Compressor Specification (Basic on 0.6 L Bottle) | Operating Pressure | Mpa | 0.7 |
| Low Pressure Air Consumption | m3/min | 1.5 |
| Blowing Pressure | Mpa | 3.5 |
| High Pressure Air Consumption | m3/min | 5 |
| Chiller Specification | Operating Pressure | kg/cm2 | 5 |
| Temperature Range | ℃ | 25 |
| Heat Consumption | kcal/hr | 40000 |
| Flow Rate | L/min | 150 |
| Machine Specification | Size (L × W × H) | m | 3.8 × 2.15 × 2.5 |
| Weight | kg | 5200 |
| Mould Plate (mm） |  |
