Features
1. EPET5-2H stretch blow molding machine employs energy saving servo control. In this way, mold open and close are fast, and 30% energy is saved compare to the same machine.
2. Mold clamping plate adopts the three-plates self-locking. It can clamp the mold fast at first, and then increase the clamping force gradually.
3. Heating box structure is designed at 6 adjusted zone, which meets different heating requirements for different tube length.
4. EPET5-2H stretch blow molding machine utilizes stable pneumatic system which helps to decrease noise and make buffer device work smoothly.
5. The injection moulding press is controlled by all-electric servo motor, avoiding the oil leakage and thus making products free from contamination.
6. This machine has two cavities and its maximum blow volume is 5 L.
7. User-friendly PLC system is applied.
8. Our stretch blow molding machines feature quick mold changing, simple installation, precise preform positioning and ideal configuration for production of medium output production needs.
Technical Specifications
| Molding Specification | Output (Basic on 0.6 L Bottle) | bph | 2500 |
| Clamping Force | kN | 480 |
| Max. Mold Stroke | mm | 120 |
| Mold Thickness | mm | 190 |
| Max. Mold Size (H × W) | mm | 4.5 × 412 |
| Stretching Stroke | mm | 400 |
| Bottom Stroke | mm | 50 |
| Cavity Distance | mm | 203.2 |
| Number of Cavities | / | 2 |
| Bottle Specification | Max. Bottle Capacity | L | 5 |
| Neck Diameter Range | mm | 30-42 |
| Bottle Diameter | mm | 160 |
| Bottle Height | mm | 350 |
| Electrisify Specification | Heating Power | kW | 86 |
| Preform Feeding Motor | kW | 0.25 |
| Rotating Motor | kW | 0.12 |
| Revolution Motor | kW | 1.5 |
| Clamping Motor | kW | 6 |
| Total Power | kW | 86 |
| Actual Power Consumption | kW | ≤ 36 |
| Air Compressor Specification (Basic on 0.6 L Bottle) | Operating Pressure | Mpa | 0.7 |
| Low Pressure Air Consumption | m3/min | 1.5 |
| Blowing Pressure | Mpa | 3.5 |
| High Pressure Air Consumption | m3/min | 4.5 |
| Chiller Specification | Operating Pressure | kg/c㎡ | 5 |
| Temperature Range | ℃ | 25 |
| Heat Consumption | kcal/hr | 40000 |
| Flow Rate | L/min | 150 |
| Machine Specification | Size (L × W × H) | m | 3.8 × 2.15 × 2.5 |
| Weight | kg | 5200 |
| Mould Plate (mm） |  |
