The production lines are shaped tube extruder, welding extruder, winding forming machine, cutting machine, and related auxiliary equipment, having a production capacity, high production efficiency, stable operation, pipe ring stiffness, unit weight per meter is small, excellent anti-creep performance, easy connection and construction and economic advantages.
Adopting composite die, two extruders unite to provide material, helix turning forming, high efficiency compound technology ensures high product quality.
Unit Type | Produced Pipe specification ∮mm
| Extruder | The total installed capacity of the production line KW load Factor 50% | Yield year | Unit Dimensions The total length of the production line L * W * H M |
model | Aspect ratio | Main motor Power KW | Heating power KW |
FD600 | ∮200- ∮600 | SJ90 | 30:1 | 75 | 43 | 230 | 75000 | 10*21*2.6 |
SJ65 | 30:1 | 45 | 25 |
FD1200 | ∮700- ∮1200 | SJ120 | 30:1 | 140 | 60 | 400 | 14400 | 10*23*2.7 |
SJ90 | 30:1 | 75 | 43 |
FD2200 | ∮1300- ∮2200 | SJ150 | 30:1 | 160 | 95 | 520 | 8000 | 10*25*2.8 |
SJ120 | 30:1 | 140 | 60 |
