PVC/UPVC/CPVC four strands pipe extrusion line, PVC/UPVC/CPVC two strands pipe extrusion line
Applicable raw materials:UPVC. CPVC
Technical specification
Model Pipe spc(mm) Extruder Max.output(kg/h) Power(kw)
GWG32-PVC 4-strands φ16-φ40 GSZ65/132 250-300 96
GWG63-PVC 2-strands φ20-φ63 GSZ80/156 350-450 136
GWG110-PVC 2-strands φ63-φ110 GSZ80/156 350-450 136
Technological advantage
1. High output capacity design,maximum speed can reach 15m/min
2. Independent vacuum and haul-off cutter device,good stability,low scraprate
3. No-dust cutter device
4. CaCo3 can add more than 200%, low cost formula
