GENOX Single Shaft Shredders

VISION Series Single Shaft Shredders are small to medium size reduction machines
suitable for processing a wide range of materials to a uniform particle size. The products
can often be sold as is, or be sent for further processing through additional equipment.
Throughputs typically range between300kg/hr 5, 000kg/hr+ depending on the model,
material type and application as below:

· Plastics Mouldings, Purgings/Lump, Profiles, Films etc.

· Timber/Wood Pallets, Joiners Waste, Green Waste etc.

· Paper & Cardboard Confidential Documents, Production Waste, Packaging Materials etc.

· Copper Cable Household, Telecoms and Industrial Cables including S. W. A

· Aluminum Used Beverage Cans (UBC's), Swarf, Cables etc.

· Textiles Carpet (Rolls & Tiles), Garments etc.

· Security Destruction Counterfeit Items, Faulty Goods, Out of Date Stock etc.

· Foam Production Waste etc.



Specification

Model: V600

Dimension: 1820x1300x1730mm
Hopper inlet: 660x600mm
Rotation diameter: 220mm
Rotor operation length: 600mm
Rotation speed: 80rpm
Ram: 500mm
Screen diameter: 40mm
Rotor knife: 23+4pcs
Counter knife: 2+2pcs
Driver power: 18.5kw
Weight: 1650kg

Standard Features

· Energy Efficient + Maximum Cutting Force & Productivity

· Shock Absorbing Gearbox reduces Stress on Drive Components

· Rotor Knives can be rotated and used on four edges before replacement.

· Long Life Counter Knives can be adjusted to maintain cutter clearance

· Quick Change Screens for accurate particle size control

· Segmented Shredding Chamber Floor with Brass Guides & PU Slides

· Twin Speed Hydraulics with integrated air cooler

· Stand Alone Electrical Control Panel with Siemens PLC Control System

· Tested, Approved and Certified to the applicable CE safety standards
