MIDDLE SIZED HDPE/LDPE FILM BLOWING MACHINE SERIES SJ-55, SJ-65 AND SJ-75 1130 Favorites

Product Categories: Single-layer Blowing Film Machine
Packaging Details:	Trademark:
Certification:
Payment Terms：
FOB:	HS Code:
Loading Port：

Ruian Songshan Plastic Machinery Co., Ltd.
Company type： Manufacturer	Credit：
Main products：Songshan is a qualified plastic machinery manufacturer that specializes in making all kinds of sealing & cutting machine, all kinds of blown film extruder and all kinds of plastic recycling machine.

Get Quotation

Contact Supplier

To：	zhang
Subject：
Message：	You can also enter 300 characters

Message has been sent successfully.

Post Buying Request

*Subject:
*Matching Rules:	Categories Keywords
*Inquiry Type:
*Keywords:	+ max five keywords
	Added:
	Note:you can add at least one keywod and most five keywords
*Categories:	Add Delete
*Detailed Description:
	Note: Please write your requirement in detail
Attachments：	+ Note: Attachments will help you get accurate solutions Note: Attachments can help you get accurate solution from suppliers
Max quotations want to receive：
	I agree to share my business card with quoted suppliers

Submit Inquiry

No matched supplier

Public souring

Your inquiry has been submitted successfully but 0 supplier matched at present, you will get quotations from Public Sourcing.

Close

Your inquiry has submited successfully and suppliers have been matched by LookingPlas,You will get the quotations as soon as possible.

Close

You had already registered,no need join again.

Registered successfully.

Sorry only Buyer can register the activities.

Model		SJ-55	SJ-65	SJ-75
Features	Raw Material	HDPE, LDPE, LLDPE; Virgin and Recycled
	Film Width	800mm	1200mm	1500mm
	Average Output	45Kgs	65Kgs	85Kgs
	Film Thickness	0.008mm-0.15mm
	Power supply	380V, 3Phase, 50Hz
	Weight	2000kgs	2600kgs	3000kgs
	Dimension	5.5×2.5×4.5M	6×3×5M	8×3×6M
Extrusion Unit	Screw&Barrel Diameter	55mm	65mm	75mm
	Screw&Barrel L/D ratio	28:1; 30:1 or 32:1
	Motor	15KW	22KW	37KW
	Gearbox	146	173	200
	Die Head Type	Rotary Die Head
	Die Size	50/80	60/100	120/160
	Heating	11KW	11KW	13KW
	Blower	3KW
Film Taking-up Tower	Upper Tower Type	Rise and Fall
	Roller Length	900mm	1400mm	1700mm
	Roller Working Way	Opened and Tightened By Air Cylinders
	Take Up Motor	1.5KW
Winding Station	Winder Type	Double winding station
	Rollers	900mm	1400mm	1700mm
	Torque Motor	15N/M
	Max. Winding Diameter	600mm
Control Panel	Temperature control	5 zone
	Electronics	Top China Brand
	Inverter Capacity	15KW/1.5KW	22KW/1.5KW	37KW/1.5KW
Optional Equipment		Hopper loader, Corona, Mechanical Screen Changer
