Detailed Product Description
SJPL-J Jumbo bag extrusion line
★ Specially designed screw can be used for both virgin and recycled material
★ Melt pressure on-line inspection and display digital intelligently
★ Six moisture absorption pipes dry the film perfectly
★ Triple folding system can be used for making stronger yarn
★ Double layer oven is opened by double cylinder which makes the structure more
★ The oven use PID intelligent temperature control and power regulator
★ Specially designed passage, making hot wind distribute evenly
★ The take-off units use casting frame to keep rollers running smooth
★ High quality reciprocated screw with critically process
The principal technical index of this line reaches international advancing level. This line has the performance of high speed,high producion,low energy consumption,good forming quality of the bobbin.The structure of this line is compact with a pleasing appearance,smooth running,flexible and reliable control excellent manufacturing technics,convenient and safe operation. It can be used in many aspects,especially in various flat forming conversion of thermoplastics, such as PP, HDPE, LDPE etc. It is mainly used for woven bag,jumbo bag,geotexile,artifical grass,backing of carpet.
Main technical parameter:
Item | SJPL-Z90×33-1000 | SJPL-Z100×33-1100 | SJPL-Z110×33-1300 | SJPL-Z120×33-1500 |
Max extrusion volume | 315kg/h | 390kg/h | 480kg/h | 530kg/h |
Screw Diameter | 90mm | 100mm | 110mm | 120mm |
Ratio of L/D | 33:1 | 33:1 | 33:1 | 33:1 |
Rotation speed of screw | 20-120r/min | 20-120r/min | 20-120r/min | 20-120r/min |
Length of mold lip | 1000mm | 1100mm | 1300mm | 1500mm |
Max production speed | 280m/min | 280m/min | 280m/min | 280m/min |
Flat yarn fibre scope | 60-200tex | 60-200tex | 60-200tex | 60-200tex |
Drawing ratio | 4-10 | 4-10 | 4-10 | 4-10 |
No.of winder | 160Spindles | 184Spindles | 216Spindles | 240Spindles |
System installed capacity | 300kw | 350kw | 410kw | 460kw |
System normal operational capacity(about) | 180kw | 210kw | 246kw | 276kw |
Overall dimension(L×W×H) | 32700×3765×2600mm | 34800×3765×2650mm | 35800×3830×2700mm | 37000×3900×2800mm |
Total weight | 26T | 27T | 29T | 32T |
