Technical indicators and uses
Specifications:Diameter Ф12-600mm
Dual alloy Depth:1.5-3mm
Chrome Thickness:0.05mm
Nitriding depth:HV850°-1000°above
Straightness:0.015mm/1000mm
Scope:ordinary plastic,PP,PE,ABS,AS,PS,PC,PET,bakelite.
Processing:Injection volume 30g-25000g,tons of all kinds of screw clamping force 250-32000,any custom feeding tube reasonable price,prompt delivery,quality service
Specifications
Note stature theory(g) | diameter×Length | Outside diameter×Length(mm) | Note stature theory(g) | Diameter×Length(mm) | Outside diameter×Length(mm) |
30-90 | Ф30×90 | Ф85×860 | 800-1250 | Ф75×1825 | Ф170×1725 |
60-125 | Ф35×910 | Ф85×860 | 1000-1500 | Ф80×2000 | Ф180×1850 |
100-150 | Ф38×935 | Ф95×900 | 1250-2000 | Ф85×2300 | Ф190×1900 |
125-160 | Ф40×980 | Ф95×910 | 2000-3000 | Ф90×3700 | Ф210×2000 |
125-300 | Ф42×1030 | Ф105×8880 | 2500-5000 | Ф100×2600 | Ф230×2405 |
250-400 | Ф45×1210 | Ф115×1165 | 3000-6000 | Ф110×2600 | Ф256×2590 |
300-500 | Ф50×1300 | Ф125×1260 | 4000-10000 | Ф120×2800 | Ф256×2800 |
450-600 | Ф55×1335 | Ф130×1320 | 6000-8000 | Ф130×3010 | Ф256×2970 |
500-700 | Ф56×1350 | Ф130×1350 | 8000-10000 | Ф145×3010 | Ф256×3200 |
500-700 | Ф60×1380 | Ф140×1350 | 10000-15000 | Ф160×3500 | Ф270×3200 |
650-800 | Ф65×1415 | Ф150×1420 | 13000-25000 | Ф170×3415 | Ф317×3380 |
700-1000 | Ф70×1790 | Ф160×1685 |
|
|
|
Use material barrel
1.Material:38CrMoAI A
Nitriding treatment,surface hardness:HV≥900
Nitride layer depth:0.5-0.8mm
2.Material:special alloy steel,after vacuum hardening heat treatment process,can greatly improve the life of three small pieces.
3.Material:tungsten carbide surface spray ultra-sound overall,improve the wear resistance of the screw.
According to customer requirements supporting the appropriate accessories,a plastic head,over an assignment,nozzle nuts,flanges,etc.,and for customers to design special screw and mapping imported parts.
