1.heater: Cast Al ( with blower cooling, stainless steel sheath).
2.electric appliance: Schneider.
3.speed adjusting: Sweden ABB frequency control, low or high speed rotary all even.
4.temperature controller: Japan Omran , temperature control precise.
5.material of barrel and screw :38CrMoAlA nitriding treatment.
6.Reducer/distributor case: hard tooth-face wheel gear reducer(Jiangyin made).
7.feeding motor: frequency control(0.75KW)
8.out-gassing :vacuum out-gassing(2.2KW)
Technical Parameters |
|
Specifications | MSGF-110 | MSGF-250 | MSGF-400 | MSGF-630 |
|
Max.pipe diameter(mm) | 125 | 250 | 400 | 630 |
|
Extruder type | MSSZ51/105 | MSSZ65/132 | MSSZ80/156 | MSSZ92/188 |
|
Extruder power (KW) | 15 | 37 | 55 | 110 |
|
Auxiliary machine power (KW) | 13 | 19 | 27.5 | 35 |
|
Production capacity (KW) | 50-150 | 150-250 | 200-400 | 400-650 |
|
