We are manufacturing barrels of twin screw extruders professionally
Specializing in the manufacture of twin screw extruder barrels, CNC machining centers are used for precision processing, the reasonable processing technology and advanced testing equipment, effectively ensure the quality of each product, "because the single-minded, so professional".


Standard Barrel Specifications Table
NO. | MODEL | L*W*H(mm) | Φ(mm) | D(mm) |
1 | 20 | 132*115*105 | Φ23 | 18.4 |
2 | 30 | 120*135*115 | Φ30.6 | 26 |
3 | 35 | 140*140*120 | Φ36 | 30 |
4 | 36 | 150*160*140 | Φ36 | 30 |
5 | 40 | 160*175*145 | Φ41.6 | 34.5 |
6 | 50 | 190*190*150 | Φ51 | 42 |
7 | 52 | 210*200*155 | Φ52 | 43 |
8 | 53 | 220*210*160 | Φ53.3 | 48 |
9 | 58 | 240*220*175 | Φ58 | 48 |
10 | 60 | 240*210*170 | Φ60 | 52 |
11 | 65 | 240*210*170 | Φ63 | 52 |
12 | 75 | 290*260*200 | Φ71.8 | 60 |
13 | 85 | 320*280*215 | Φ81.9 | 67.8 |
14 | 92 | 360*310*240 | Φ92 | 78 |
15 | 95 | 360*310*240 | Φ94 | 78 |
16 | 110 | 420*330*240 | Φ109 | 91.5 |
17 | 125 | 500*390*290 | Φ125 | 98 |
18 | 135 | 520*440*340 | Φ134 | 110 |
PRODUCT DISPLAY
